4. Image resolution

The resolution test of the Canon EF 40 mm f/2.8 STM was based on RAW files from the Canon EOS 1Ds MkIII body. In the case of that camera the decency level is situated near 30-32 lpmm and the best fixed-focus lenses can reach as high as 44-46 lpmm.

Let’s glance at a graph below to see how the tested lens fares in the frame centre, on the edge of the APS-C sensor and on the edge of full frame.

Canon EF 40 mm f/2.8 STM - Image resolution



Please Support Us

If you enjoy our reviews and articles, and you want us to continue our work please, support our website by donating through PayPal. The funds are going to be used for paying our editorial team, renting servers, and equipping our testing studio; only that way we will be able to continue providing you interesting content for free.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

When it comes to the performance in the frame centre you can only praise it. At the maximum relative aperture the tested lens reaches 34 lpmm so a result which guarantees you sharp and useful photos. The Canon 2.8/40 reaches the peak of its possibilities by f/4.0 and f/5.6 where it gets to the value of almost 45 lpmm. It is a very good result, you can even say excellent if you remember we deal here with one of these „pancake” devices which never break resolution records.

We don’t have any reservations conserning the performance on the edge of the APS-C sensor either. Although officially at the maximum relative aperture the lens doesn’t reach the value of 30 lpmm you can say that even there the lens fulfills our usefulness criteria, taking into account the margin of measurement errors. On stopping down the image quality improves but that improvement is not especially effective. Those results are good for sure but they won’t bowl you over.

The edges of full frame are often the Achilles heel of „pancakes”. Taking it into account, our assessment of the Canon’s 2.8/40 performance shouldn’t be negative. Perhaps the maximum aperture is not exactly completely useful but it really lacks little to be so. After stopping down by one stop you get very decent photos. It is worrisome, though, that further stopping down is not especially efficient and in the wide range of apertures, from f/4.0 to f/11, we get just decent results, on the level of 30-32 lpmm.

To sum up: we are pleasantly surprised with the achievements of the Canon 2.8/40. It really performs more like a typical „prime”, without showing the characteristic weaknesses of „pancakes” in an evident way.

Canon EF 40 mm f/2.8 STM - Image resolution
