Lens review

Samyang T-S 24 mm f/3.5 ED AS UMC

21 May 2013
Arkadiusz Olech

2. Pictures and parameters

Manufacturer Samyang
Model T-S 24 mm f/3.5 ED AS UMC
Lens style Wide angle
Focal length 24 mm
Maximum aperture f/3.5
Angle of view 83.5 o
Closest focusing distance 0.2 m
Maximum magnification
Minimum aperture 22
Number of diaphragm blades 6
Auto focus type MF
Lens Construction 16 elements / 11 groups
Filter diameter 82 mm
Macro No
Available mounts Canon EF
Nikon F
Sony A / Minolta
Pentax K
Dimensions 110.5 x 86 mm
Weight 680 g
Additional information Tilt-Shift type lens.
2 aspherical lens, 2 ED glass lens
Maximum Tilt amount:±8.5˚
Maximum Shift amount: ±12 mm
Between Tilt and Shift Rotation: 90˚ Left (click-stop for each 30˚step)
Mount Rotation: 90˚ Right and Left (click-stop for each 30˚ step)
