LensTip.com

Lens review

Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH

23 September 2019
Arkadiusz Olech

5. Chromatic and spherical aberration

Chromatic aberration

Photos below show clearly that the tested lens doesn't have any problems with longitudinal chromatic aberration. It's worth noticing that in that category the standards were set very high because you deal with both good aperture fastness and a wide range of angles of view.

Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH - Chromatic and spherical aberration


Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH - Chromatic and spherical aberration


The graph below allows you to assess how the Panaleica 10-25 mm deals with lateral chromatic aberration.

Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Images practically free of the aberration you get just in the middle of the focal range; at both ends of the spectrum the aberration level is the highest. At the maximum focal length it depends weakly on aperture values, staying all the time near 0.09-0.10%. Such results we consider to be on the borderline between low and average level. In the case of the widest angle of view chromatic aberration is low only for the closest area of the maximum relative aperture. From f/2.8 onwards it starts approaching medium values.

E-M5 II, RAW, 17 mm, f/1.7 E-M5 II, RAW, 25 mm, f/1.7
Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH - Chromatic and spherical aberration Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH - Chromatic and spherical aberration


Spherical aberration

In the first photos of this chapter you can see that the lens doesn't have any 'focus shift' effect. Circles we got before and after the focus aren't identical, but they don't feature any distinct differences either. All of this make us say there are no significant problems connected to spherical aberration correction.

Olympus E-M5 II, 25 mm, f/1.7, in front of Olympus E-M5 II, 25 mm, f/1.7, behind
Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH - Chromatic and spherical aberration Panasonic Leica DG Vario-Summilux 10-25 mm f/1.7 ASPH - Chromatic and spherical aberration
