Sigma A 14-24 mm f/2.8 DG DN

23 December 2019
Arkadiusz Olech

5. Chromatic and spherical aberration

Chromatic aberration

Photos below show that the Sigma A 14-24 mm f/2.8 DG DN doesn't feature any significant problems with longitudinal chromatic aberration. Even at the maximum relative aperture it would be difficult to notice any traces of colouring in out-of-focus areas – it means that aberration is corrected very well.

Sigma A 14-24 mm f/2.8 DG DN - Chromatic and spherical aberration


In similarly positive terms you can describe the correction of lateral chromatic aberration; the graphs below show its levels respectively on the edge of the APS-C sensor and on the edge of full frame.

Sigma A 14-24 mm f/2.8 DG DN - Chromatic and spherical aberration

Sigma A 14-24 mm f/2.8 DG DN - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


The highest results can be noticed at 19 mm but even there they never exceed 0.06%. It means that, at the majority of focal lengths and apertures, lateral chromatic aberration is very low and you might experience a lot of problems if you want to observe even the slightest trace of it in real life photos. It is a performance very similar to that of the reflex camera Sigma in which case the aberration didn't exceed 0.05%. Both lenses deal with lateral chromatic aberration in an exemplary manner and, with such parameters, it is really something impressive and praiseworthy.

A7R II, RAW, 19 mm, f/2.8 A7R II, RAW, 24 mm, f/22.0
Sigma A 14-24 mm f/2.8 DG DN - Chromatic and spherical aberration Sigma A 14-24 mm f/2.8 DG DN - Chromatic and spherical aberration


Spherical aberration

First photos of this chapter show a slight 'focus shift' effect because, as you pass from f/2.8 to f/4.0, depth of field moves slightly toward smaller distances. One glance at circles of light we got before and after the focus and it's obvious that the intensity of their outer rim differs a lot. Both these features suggest that, at least at longer focal lengths, spherical aberration hasn't been corrected perfectly well.

A7R II, 24 mm, f/2.8, in front of A7R II, 24 mm, f/2.8, behind
Sigma A 14-24 mm f/2.8 DG DN - Chromatic and spherical aberration Sigma A 14-24 mm f/2.8 DG DN - Chromatic and spherical aberration
