LensTip.com

Lens review

Canon EF-S 17-55 mm f/2.8 IS USM

23 September 2007
Arkadiusz Olech

3. Build quality

The first thing that catches the eye is the size of the lens. As an upgrade for a kit lens, this lens is huge. The picture below shows that the lens is almost as tall as the Canon 100-300 mm and is notably thicker and heavier. While the big size of the lens may be a detriment, some might consider that the big size might mean we are getting optically great equipment. You cannot really make a lens of a fixed aperture of f/2.8, image stabilization and small vignetting, yet still be small at the same time.

Canon EF-S 17-55 mm f/2.8 IS USM - Build quality


Although the lens is not as sturdy as an L-grade lens, one cannot really criticize its build quality. On the other hand there are a few L-grade lenses that are significantly cheaper than the EF-S 17-55 mm. And because of the use of some die-cast magnesium alloy in it's build, it is much sturdier.


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Canon EF-S 17-55 mm f/2.8 IS USM - Build quality


As far as the inside of the lens is concerned, it's pretty impressive. The lens, despite a zoom no bigger than 3x, contains 19 elements arranged in 13 groups. It's worth mentioning that some elements were made of low dispersion UD glass and there are aspheric lenses used in the system. The seven blade lens hood was a nice addition as well.

Canon EF-S 17-55 mm f/2.8 IS USM - Build quality

There is no doubt about the fact that usage of a 3 degree image stabilization (IS) had an influence on the lens size. The question about the validity of this operation in the lens, which has a focal range of 17-55 mm and a very good aperture of f/2.8, makes perfect sense. There is no doubt that the presence of IS has a big influence on the size and price of the lens. We have to honestly say that IS comes in handy sometimes and this tested model works perfectly well, as can be observed in the picture below.

Canon EF-S 17-55 mm f/2.8 IS USM - Build quality


Although the lens doubles its size while increasing the focal length, the front lens doesn't rotate. It maintains its position while focusing and this should make all filter users very content.
