LensTip.com

Lens review

Sigma A 24 mm f/1.4 DG HSM

8 March 2015
Arkadiusz Olech

5. Chromatic and spherical aberration

Chromatic aberration

When it comes to the longitudinal chromatic aberration neither the Canon EF 24 mm f/1.4L USM II, nor the Nikkor AF-S 24 mm f/1.4G distinguished themselves. The Canon’s level was huge, the Nikkor’s – medium. How the Sigma fares here? Let’s glance at photos below.

Sigma A 24 mm f/1.4 DG HSM - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


The aberration is noticeable both by f/1.4 and by f/2.0 but its level is not high. You can say it is somewhere near the borderline between medium and low values. The Sigma compares favourably with its rivals.

Now let’s check its lateral chromatic aberration correction. The graph below shows its performance on the edge of the APS-C sensor and full frame.

Sigma A 24 mm f/1.4 DG HSM - Chromatic and spherical aberration


Here the Sigma A 1.4/24 definitely deserves our praise. At the maximum relative aperture the results reach less than 0.05% so a very low level. On stopping down the aberration increases but it never exceeds 0.09% so never gets near even medium values.

The rivals presented here a slightly worse performance. The Canon had values of 0.07–0.09%, no matter what sensor or aperture you applied and the Nikkor’s aberration near the maximum relative aperture increased to 0.10% and then dropped to 0.07–0.08% on stopping down.

Canon 5D III, f/1.4 Canon 5D III, f/8.0
Sigma A 24 mm f/1.4 DG HSM - Chromatic and spherical aberration Sigma A 24 mm f/1.4 DG HSM - Chromatic and spherical aberration



Spherical aberration

The tested lens didn’t have any ‘focus shift’ effect which suggest the spherical aberration level cannot be high. The crops below prove that as well: the light circles we got in front of and behind the focal point don’t differ so the spherical aberration correction seems to be good – no serious complaints here.

Canon 5D III, f/1.4, in front of Canon 5D III, f/1.4, behind
Sigma A 24 mm f/1.4 DG HSM - Chromatic and spherical aberration Sigma A 24 mm f/1.4 DG HSM - Chromatic and spherical aberration
