LensTip.com

Lens review

Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED

25 August 2018
Arkadiusz Olech

6. Distortion

When it comes to a fisheye lens, any distortion measurement is a bit art for art’s sake because the mapping in this type of instruments is distorted by definition. It’s worth mentioning that with such wide angles of view the curvature of straight lines makes images more similar to the ones you see with your naked eye; they seem more natural than exaggerated distortions and deformations visible in the corners of ultra wide angle rectilinear lenses.

Following our research instinct we still want to share the values we got at particular focal lengths. On the smaller sensor of the Nikon D500 at 8 mm they oscillate close to -34%, at 12 mm they stay near -22%, and at 15 mm they decrease to -16%.

After passing to full frame at the shortest focal length the distortion reaches -45%, at 12 mm it decreases to -35% and then it stops by -26% at 15 mm.


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Nikon D500, 8 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion
Nikon D500, 10 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion
Nikon D500, 12 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion
Nikon D500, 15 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion

Nikon D3x, 8 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion
Nikon D3x, 10 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion
Nikon D3x, 12 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion
Nikon D3x, 15 mm
Nikon Nikkor AF-S Fisheye 8-15 mm f/3.5-4.5E ED - Distortion
