Lens review

Sigma C 90 mm f/2.8 DG DN

8 November 2021
Maciej Latałło

5. Chromatic and spherical aberration

Chromatic aberration

Inside the Sigma you get a lot of low-dispersion elements for a fixed-focal f/2.8 lens, five to be precise. Despite that fact, the constructors weren't able to reduce longitudinal chromatic aberration to zero. At the maximum relative aperture the area before the focus has slightly red colouring and behind the focus the colouring changes into green. That effect is reduced significantly on stopping down the aperture to f/4.0 but even then you cannot eliminate it completely.

Sigma C 90 mm f/2.8 DG DN - Chromatic and spherical aberration

Now let's check the correction of lateral chromatic aberration – an appropriate graph you can find below.

Sigma C 90 mm f/2.8 DG DN - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


The aberration increases quite quickly with stopping down the aperture; fortunately, in case of this lens, f/2.8 and f/4.0 will be used most often; in that aperture range aberration is practically zero, from 0.02 to 0.03% to be precise. What's more, such a low level is kept by the lens even if you stop down the aperture to f/8.0. Medium values appear only from f/11 onwards and only on the edge of the APS-C sensor.

A7R III, RAW, FF, f/2.8 A7R III, RAW, FF, f/22.0
Sigma C 90 mm f/2.8 DG DN - Chromatic and spherical aberration Sigma C 90 mm f/2.8 DG DN - Chromatic and spherical aberration

Spherical aberration

First photos of this chapter have a slight 'focus shift' effect – you can notice that, on stopping down the aperture, depth of field is moved toward greater distances. Problems with correction of spherical aberration can also be noticed in defocused light circles – the one before the focus has a darker edge and the one behind the focus features a brighter rim.

Both effects, described in this chapter, show unanimously that the Sigma C 90 mm f/2.8 DG DN cannot correct spherical aberration in a perfect way.

A7R III, f/2.8, before A7R III, f/2.8, after
Sigma C 90 mm f/2.8 DG DN - Chromatic and spherical aberration Sigma C 90 mm f/2.8 DG DN - Chromatic and spherical aberration
