LensTip.com

Lens review

Sigma 70-200 mm f/2.8 EX DG APO OS HSM

6 September 2010
Arkadiusz Olech

9. Ghosting and flares

The lenses of 70-200 mm f/2.8 class has often had a lot of issues concerning the work against bright light. It is due to two factors. Firstly, we deal here with constructions closed at one end by big front element which usually is not covered by anything and catches side light easily. Secondly, these are very complex instruments in terms of optics, with even several dozen air-to-glass surfaces which must be anti-reflection coated. Even if you use the best coatings available on the market, with such a huge amount of surfaces to be covered the transmission of a lens will never be perfect; the lost light wanders inside the lens causing flares and the decrease of contrast.

The Sigma 70-200 mm is not an exception to the rule. Before we show you photos taken typically in every our test (i.e. with the sun near one of the frame corners) let’s have a glance at a bit different view.

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


In this case the sun shone toward the lens but it was far away from the frame. The photo presents the ground floor of a 3-storeyed tenement building and our day star was shining even about 20 degrees above it. Although the distance to the frame was significant still we can notice a greenish gleam, registered in the photo.

When the conditions become even more difficult, catching flares is much easier. At 70 mm focal length the flares are still quite intense. At longer focal lengths the problems are less pronounced. It can be seen very well looking at the examples below.

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares

Sigma 70-200 mm f/2.8 EX DG APO OS HSM - Ghosting and flares
