Venus Optics LAOWA 17 mm f/1.8 MFT II

28 January 2020
Arkadiusz Olech

5. Chromatic and spherical aberration

Chromatic aberration

The tested lens doesn't have any problems with longitudinal chromatic aberration – its influence on image quality remains slight and if you spot any colouring in blurry areas positioned further in the frame, its level is not especially bothersome.

Venus Optics LAOWA 17 mm f/1.8 MFT II - Chromatic and spherical aberration


In the case of the lateral chromatic aberration the lens can be assessed equally well – a graph below presents its performance depending on the aperture value.

Venus Optics LAOWA 17 mm f/1.8 MFT II - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


The results are more or less the same and they oscillate near 0.03%. Such a value can be described as very low so there's no danger you can notice chromatic aberration in typical photos taken with this lens.

Olympus E-M5 II, RAW, f/2.8 Olympus E-M5 II, RAW, f/8.0
Venus Optics LAOWA 17 mm f/1.8 MFT II - Chromatic and spherical aberration Venus Optics LAOWA 17 mm f/1.8 MFT II - Chromatic and spherical aberration


Spherical aberration

When it comes to the level of spherical aberration it can be described as low. If you take a closer look at first photos from this chapter you can notice a very slight focus shift toward greater distances on stopping down the aperture from f/1.8 to f/2.8. A similar situation can be observed while comparing defocused circles of light – the rim from the circle before the focus is slightly more accented. Apart from that, you can't see anything alarming.

Olympus E-M5 II, f/1.8, in front of Olympus E-M5 II, f/1.8, behind
Venus Optics LAOWA 17 mm f/1.8 MFT II - Chromatic and spherical aberration Venus Optics LAOWA 17 mm f/1.8 MFT II - Chromatic and spherical aberration
