Lens review

Canon EF 16-35 mm f/4L IS USM

22 July 2014
Arkadiusz Olech

9. Ghosting and flares



Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Ghosting and flares are serious problems of the tested lens. You see them at all focal lengths, no matter what aperture you apply and where the source of light is. Even if the sun is situated noticeably outside the frame the photo might still feature colourful arcs influencing it in a significant way.

There are more reflections on the smaller sensor – it is a bit connected with the high vignetting level on full frame which helps to damp down the flares. The sun in the frame corner is weaker by about 2 EV right at the start – because such is the vignetting value for the corner. What’s more, the reflections which might appear in the opposite corner are weakened by the same value as well. Our reasoning is confirmed by the fact that on full frame, after a significant stopping down (so eliminating the vignetting), the flares become actually brighter.

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares

Canon EF 16-35 mm f/4L IS USM - Ghosting and flares
