5. Chromatic and spherical aberration

Chromatic aberration

Longitudinal chromatic aberration is not corrected in a perfect way – its slight influence can be noticed near the maximum relative aperture. Still the observed level of the aberration is nothing to carp about and the tested lens shouldn’t be criticized because of it, especially that by f/2.0 the problems practically cease to exist. It also should be noticed that its result is better than the result of its predecessor.

Sigma A 85 mm f/1.4 DG HSM - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


Now let’s check how the Sigma A 1.4/85 deals with the lateral chromatic aberration – the appropriate graph is shown below.

Sigma A 85 mm f/1.4 DG HSM - Chromatic and spherical aberration


The results are quite sensational. No matter what detector is used, the aberration level oscillates near 0.01- 0.02%. It means you’ll have problems with noticing the chromatic aberration in real life photos even if you examine blown-up crops in great detail. Similarly excellent values in this category had both Zeisses, the Otus and the Milvus; the tested lens fares a bit better than its direct predecessor, the Canon EF 85 mm f/1.2L II USM and the Nikkor AF-S 85 mm f/1.4G.

Canon 5D III, f/1.4 Canon 5D III, f/5.6
Sigma A 85 mm f/1.4 DG HSM - Chromatic and spherical aberration Sigma A 85 mm f/1.4 DG HSM - Chromatic and spherical aberration



Spherical aberration

First photos of this chapter don’t feature any noticeable “focus shift”. Still if you look closely you can see a slight shift of the depth of field toward the greater distances when you pass from f/1.4 to f/2.0. Looking at the circles of light you can also perceive vestigial spherical aberration. Overall the image looks very nice but the circle in front of the focus has soft edges and the circle behind the focus – a delicate outline.

Both these effects mean the spherical aberration is not corrected in a perfect way but its influence remains slight so it would be difficult to consider it a serious flaw. That verdict is additionally confirmed by high resolution values across the frame by f/1.4 and lack of characteristic mist in photos.

Canon 5D III, f/1.4, in front of Canon 5D III, f/1.4, behind
Sigma A 85 mm f/1.4 DG HSM - Chromatic and spherical aberration Sigma A 85 mm f/1.4 DG HSM - Chromatic and spherical aberration
