Lens review

Sigma C 18-200 mm f/3.5-6.3 DC Macro OS HSM

27 June 2014
Arkadiusz Olech

5. Chromatic and spherical aberration

Chromatic aberration

As you can notice in photos below the longitudinal chromatic aberration of the tested lens is practically imperceptible. Here the Sigma can be only praised.

Sigma C 18-200 mm f/3.5-6.3 DC Macro OS HSM - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


The lateral chromatic aberration in 18-200 mm class lenses is not as easy to correct, though. Despite that fact the producers, with several versions of the Sigma 18-200 mm model, managed to achieve a noticeable progress. The 18–200 mm f/3.5–6.3 DC OS lens had the maximum lateral chromatic aberration level of 0.14%, never descending lower than 0.08%. Its successor, the 18–200 mm f/3.5–6.3 II DC OS HSM, could get values as low as 0.02-0.05%, not exceeding a value of 0.12% anywhere.

The graph shown below proves that with the newest model the results are similar.

Sigma C 18-200 mm f/3.5-6.3 DC Macro OS HSM - Chromatic and spherical aberration


The highest aberration you see at the widest angle: no matter what aperture you employ it will keep a constant level of 0.12-0.13%. Although these values are still deemed medium, they are in fact very close to high. At the longer end of the focal range there are less problems though. In the middle of the range the aberration is slight and at 200 mm it reaches a medium level.

It’s obvious Sigma doesn’t’ repeat the mistakes of its rivals. You can remind here the result of almost 0.26%, reached by the Canon EF-S 18–200 mm f/3.5–5.6 IS at 100 mm focal length or the result of the Tamron and the Sony DT 18–200 mm f/3.5–6.3 – both those devices got to 0.17% at their maximum focal length.

Sigma C 18-200 mm f/3.5-6.3 DC Macro OS HSM - Chromatic and spherical aberration



Spherical aberration

The lens didn’t have any ‘focus shift’ tendency. Defocused images of light points in front of and behind the focus don’t differ significantly. It all makes us say that the tested lens corrects the spherical aberration in the right way.

Sigma C 18-200 mm f/3.5-6.3 DC Macro OS HSM - Chromatic and spherical aberration
