Lens review

Sigma 70-200 mm f/2.8 II EX APO DG Macro HSM

15 September 2009
Arkadiusz Olech

8. Vignetting

At the sensor of 1.5x focal factor vignetting should be no problems for us. At 70 mm focal length we don’t need to bother at all, as there at f/2.8 the light falloff in the corners of the frame equals only 10% (-0.31 EV), and at f/4.0 falls to 2%.

Sigma 70-200 mm f/2.8 II EX APO DG Macro HSM - Vignetting


It’s similar at 135 mm. At the maximum aperture vignetting reaches only 14% (-0.43 EV) and falls to 3% at f/4.0.


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

The biggest chance of seeing vignetting we have at 200 mm focal length and the maximum aperture, where the light falloff in the corners equals 24% (-0.84 EV). The problem vanishes completely at f/4.0 where the measured value of vignetting equaled 10%.

Situation improves again after mounting the converter. In the case of working with it, at the maximum aperture, we have vignetting of 13% (-0.41 EV), which vanishes at f/5.6 (3%).

In this category we think we have a small improvement over the predecessor. The values themselves are the same or slightly smaller with the successor, but if we take into consideration the fact that the version II was tested on a sensor of slightly larger dimensions, we can see slight improvement.


Sigma 70-200 mm f/2.8 II EX APO DG Macro HSM - Vignetting

Sigma 70-200 mm f/2.8 II EX APO DG Macro HSM - Vignetting
