LensTip.com

Lens review

Voigtlander Nokton 10.5 mm f/0.95

18 July 2015
Arkadiusz Olech

7. Coma, astigmatism and bokeh

The coma correction is dramatically bad – the coma level of the lens is simply huge. You can notice it not only at the maximum relative aperture but also after stopping down by 1-2 EV.

E-M10, 10.5 mm, f/0.95, center E-M10, 10.5 mm, f/0.95, corner
Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh
E-M10, 10.5 mm, f/1.4, center E-M10, 10.5 mm, f/1.4, corner
Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh


It is not the end of problems. The coma makes itself felt not only in the very corners of the frame. Among our sample shots you can find photos of the night sky which allow you to assess the full extent of the problem. The crop presented below is a 1:1 photo of the sky taken by f/0.95, featuring the Lyra constellation and its brightest star, Vega. The area shown here was situated in the photo about half the distance between the corner and the center of the frame; still as you can clearly notice the coma remains very pronounced, contributing greatly to the worsening of the image quality on the edge of the frame and its extended neighbourhood.


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Olympus E-M10, JPEG, f/0.95, exp. 20 s.
Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh


Another off-axis aberration, the astigmatism, is also corrected badly. The average difference between horizontal and vertical MTF50 function values amounted to as much as 25%. What’s more, that aberration is still distinctly visible by f/4.0 and f/5.6. Only near f/8.0 it becomes slight. These results are very bad indeed…

When it comes to the appearance of blurry areas there are no good news either. The light spread in the circles is far from even and the darkening of the circle, connected to the vignetting, is visible not only in the frame corners. Additionally you can spot a net of concentric circles. There is another problem: it seems in order to get nice, round circles it is not enough to use a lot of aperture blades, you should also focus on rounding them properly. The Voigtlander clearly failed here as well - despite ten blades, it would be difficult to call the image of its aperture round…

E-M10, 10.5 mm, f/0.95, center E-M10, 10.5 mm, f/0.95, corner
Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh
E-M10, 10.5 mm, f/1.4, center E-M10, 10.5 mm, f/1.4, corner
Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh
E-M10, 10.5 mm, f/2.0, center E-M10, 10.5 mm, f/2.0, corner
Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh Voigtlander Nokton 10.5 mm f/0.95 - Coma, astigmatism and bokeh
