LensTip.com

Lens review

Nikon Nikkor Z 40 mm f/2.0

26 November 2021
Maciej Latałło

5. Chromatic and spherical aberration

Chromatic aberration

In the case of the tested lens you deal with an angle of view a bit wider than in case of a typical stadard lens and a quite sensible f/2.0 aperture. Such a combination is not easy to correct when it comes to longitudinal chromatic aberration; still, despite a simple optical system and lack of low dispersion elements Nikon managed splendidly well in this area. Even at the maximum relative aperture images outside depth of field don't show any significant colouring – a round of applause!

Nikon Nikkor Z 40 mm f/2.0 - Chromatic and spherical aberration

What about lateral chromatic aberration – will the performance be equally good? Let's find out by glancing at a graph below.

Nikon Nikkor Z 40 mm f/2.0 - Chromatic and spherical aberration


Please Support Us

The coronavirus crisis has been adversely affecting many businesses and, sad but true, ours is not an exception. Despite that difficult situation we would like to preserve continuity and high quality of publications available on all our websites. Still, we are now aware it might be impossible without additional financial help. That's why we would like to ask all those who visit, read, and care about Optyczne.pl, LensTip.com i Allbinos.com for support - it's enough you send us a small sum of money via PayPal. If a lot people decide to support our websites we think we'll stand a chance and survive next months without any lasting harm. We count on your support and understanding, stay safe and be healthy.

- - - - - - - - - - - - - - - - - advertisement - - - - - - - - - - - - - - - - -

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


The aberration depends weakly on aperture values but it is stronger correlated with the position in the frame. On the edge of the full frame you deal with values ranging from 0.06% to 0.08% so being on a level that can still be described as low. On the edge of the APS-C /DX sensor the situation is a bit worse as this aberration increases to a borderline between low and medium values. Overall the performance in this category can be called satisfactory – chromatic aberration shouldn't overly bother you in real life photos.

Nikon Z7, RAW, f/2.0 Nikon Z7, RAW, f/16.0
Nikon Nikkor Z 40 mm f/2.0 - Chromatic and spherical aberration Nikon Nikkor Z 40 mm f/2.0 - Chromatic and spherical aberration

Spherical aberration

First photos of this chapter show a slight 'focus shift' effect as, on stopping down the aperture from f/2.0 to f/2.8, depth of field is moved slightly toward greater distances. Still, when it comes to correction of spherical aberration, circles of light we got before and behind the focus don't feature any serious problems; they aren't perhaps identical but differences between them can hardly be called significant.

Nikon Z7, f/2.0, before Nikon Z7, f/2.0, after
Nikon Nikkor Z 40 mm f/2.0 - Chromatic and spherical aberration Nikon Nikkor Z 40 mm f/2.0 - Chromatic and spherical aberration
